A17039/64
A17039/64
A17039/64
A17039/64

A17039/64

UGC DOR5968814
par Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$51.06 CAD - $51.06 CAD
$51.06 CAD
$51.06 CAD - $51.06 CAD
$51.06 CAD

Vendu en lots de : 1

Foret de longueur standard avec queue cylindrique réduite de 1/2", de diamètre 0,6094" (39/64) et d'une longueur totale de 6" et longueur de goujure de 3.1/8" selon la norme DORMER avec un angle de pointe de 118°, HSS avec finition trempée à la vapeur pour un perçage 4xD sans débourrage dans l'acier

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)A17039/64
GradeTrempé à la vapeur
Product Number5968814
Product FamilyA170
Dimensions
Cutting Diameter — in (DC)0.6094"
Cutting Diameter — mm (DC)15.48 mm
Cutting Diameter — Fractional39/64
Overall Length — in (OAL)6.0"
Overall Length — mm (OAL)152.4 mm
Flute Length — in (LCF)3.125"
Flute Length — mm (LCF)79.4 mm
Length × Diameter Ratio4
Connection Dia. — in (DCON)0.5"
Connection Dia. — mm (DCON)12.7 mm
Drill Point Angle (SIG)118°
Tool Information
ShankQueue cylindrique réduite
Direction of ToolD'accord
StandardNorme de travail
Reference Numbers
EDP Number121900
EAN7320760121900
File Type Download
A17039/64 — 3D Model STP Download
A17039/64 — Line Drawing PDF Download
