RNMU 1205MOT-MF:M6030

RNMU 1205MOT-MF:M6030

UGC DOR8547844
par Dormer Pramet
Primary Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$21.73 CAD - $21.73 CAD
$21.73 CAD
$21.73 CAD - $21.73 CAD
$21.73 CAD

Vendu en lots de : 10

Plaquette de fraisage double face RNMU 1205 avec brise-copeaux, ronde pour une profondeur de coupe maximale de 6 mm, avec une précision d'indexation selon la classe de tolérance ISO-M et une géométrie MF avec arêtes de coupe arrondies et facette, carbure WC-Co revêtu PVD M6030 dans les gammes de qualités ISO M15-M35 et S15-S25 pour l'usinage de l'acier inoxydable et du superalliage avec des fraises à copier ISRN12/SRN12

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)RNMU 1205MOT-MF:M6030
GradeM6030
Chipbreaker (CBMD)MF
Product Number8547844
Product FamilyRNMU12
Insert Geometry
Insert DesignUMIIRN
Insert Shape Code (SC)R - tour
Inscribed Circle Dia. — in (IC)0.472"
Inscribed Circle Dia. — mm (IC)12.0 mm
Insert Thickness — in (S)0.213"
Insert Thickness — mm (S)5.4 mm
Dimensions
Connection Dia. — in (DCON)0.492"
Tool Information
Tool DesignSRN12
Reference Numbers
EDP Number8547844
EAN3603604262255
Material Group Suitability
M — Stainless Steel Usage principal
S — High Temperature Alloys Usage principal
File Type Download
RNMU 1205MOT-MF:M6030 — Line Drawing PDF Download
