UGC DOR5968054
par Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$10.11 CAD - $10.11 CAD
$10.11 CAD
$10.11 CAD - $10.11 CAD
$10.11 CAD

Vendu en lots de : 10

Foret étagé à queue cylindrique, diamètre 5,4 mm, longueur totale 66 mm et longueur de goujure 28 mm, conforme à la norme DIN 1897, avec pointe auto-centrante à 135°, en HSS-E cobalt, finition bronze, pour un perçage sans débourrage jusqu'à 2,5xD dans l'acier inoxydable et les superalliages

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)A1175.4
GradeBronze
Product Number5968054
Product FamilyA117
Dimensions
Cutting Diameter — in (DC)0.2126"
Cutting Diameter — mm (DC)5.4 mm
Overall Length — in (OAL)2.5984"
Overall Length — mm (OAL)66.0 mm
Flute Length — in (LCF)1.1024"
Flute Length — mm (LCF)28.0 mm
Length × Diameter Ratio2.5
Connection Dia. — in (DCON)0.2126"
Connection Dia. — mm (DCON)5.4 mm
Drill Point Angle (SIG)135°
Tool Information
ShankTige cylindrique
Direction of ToolD'accord
StandardDIN 1897
Reference Numbers
EDP Number15568
EAN7320760015568
File Type Download
A1175.4 — 3D Model STP Download
A1175.4 — Line Drawing PDF Download
