A1255/64X160
A1255/64X160
A1255/64X160
A1255/64X160

A1255/64X160

UGC DOR5968859
par Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$40.94 CAD - $40.94 CAD
$40.94 CAD
$40.94 CAD - $40.94 CAD
$40.94 CAD

Vendu en lots de : 1

Foret extra-long avec queue cylindrique, diamètre 0,0781" (5/64) avec une longueur totale de 160 mm et une longueur de coupe de 100 mm selon la norme BS 328 avec pointe conique à 118°, en HSS avec finition brillante pour perçage 10xD sans débourrage dans l'acier

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)A1255/64X160
GradeLumineux
Product Number5968859
Product FamilyA125
Dimensions
Cutting Diameter — in (DC)0.0781"
Cutting Diameter — mm (DC)1.98 mm
Cutting Diameter — Fractional5/64
Overall Length — in (OAL)6.2992"
Overall Length — mm (OAL)160.0 mm
Flute Length — in (LCF)3.937"
Flute Length — mm (LCF)100.0 mm
Length × Diameter Ratio10
Connection Dia. — in (DCON)0.078"
Connection Dia. — mm (DCON)1.98 mm
Drill Point Angle (SIG)118°
Tool Information
ShankQueue cylindrique
Direction of ToolD'accord
StandardBS 328
Reference Numbers
EDP Number173688
EAN7320760173688
File Type Download
A1255/64X160 — 3D Model STP Download
A1255/64X160 — Line Drawing PDF Download
