A221N00
A221N00

A221N00

UGC DOR5969071
par Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$10.33 CAD - $10.33 CAD
$10.33 CAD
$10.33 CAD - $10.33 CAD
$10.33 CAD

Vendu en lots de : 1

Foret à centrer (foret-taraud combiné) avec forme conique droite à 60°, double extrémité et corps cylindrique, taille 00 avec diamètre de perçage de 0,0250", un diamètre de corps de 1/8" et une longueur totale de 1,1/8", selon la norme ANSI pour produire des trous de centrage de forme A, en HSS-E à base de cobalt et finition brillante pour l'usinage des aciers de décolletage, des aciers au carbone et alliés et de la fonte grise

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)A221N00
GradeLumineux
Product Number5969071
Product FamilyA221
Dimensions
Cutting Diameter — in (DC)0.025"
Cutting Diameter — mm (DC)0.64 mm
Overall Length — in (OAL)1.125"
Overall Length — mm (OAL)28.58 mm
Length × Diameter Ratio1.5
Connection Dia. — in (DCON)0.125"
Connection Dia. — mm (DCON)3.18 mm
Drill Point Angle (SIG)118°
Tool Information
ShankQueue cylindrique
Direction of ToolD'accord
StandardANSI
Reference Numbers
EDP Number241851
EAN7320760241851
File Type Download
A221N00 — Line Drawing PDF Download
