E5245/8NO2
E5245/8NO2
E5245/8NO2

E5245/8NO2

UGC DOR5976118
par Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$59.73 CAD - $59.73 CAD
$59.73 CAD
$59.73 CAD - $59.73 CAD
$59.73 CAD

Vendu en lots de : 1

Taraud à main à coupe droite NO2 avec entrée de 4 à 6 filets, pour filetage UNF 5/8" au pas de 18 filets par pouce et tolérance 2B, dimensions selon norme ISO 529 avec queue de 12,5mm et carré d'entraînement de 10,0mm, en HSS brillant pour taraudage de trous débouchants ou borgnes jusqu'à 1,5xD dans les aciers de décolletage, les aciers au carbone non alliés, le cuivre ou les alliages de cuivre

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)E5245/8NO2
GradeLumineux
Product Number5976118
Product FamilyE524
Dimensions
Overall Length — in (OAL)4.0157"
Overall Length — mm (OAL)102.0 mm
Length × Diameter Ratio1.5
Connection Dia. — in (DCON)0.4921"
Connection Dia. — mm (DCON)12.5 mm
Number of Flutes (NOF)4
Threading
Thread Diameter Size (TDZ)5/8
Thread Diameter — in (TD)0.625"
Thread Diameter — mm (TD)15.875 mm
Thread Form (THFT)UNF - Unified Fine
Threads per Inch (TPI)18.0
Tool Information
ShankQueue cylindrique avec carré
Direction of ToolD'accord
StandardISO 529
Reference Numbers
EDP Number98080
EAN7320760098080
File Type Download
E5245/8NO2 — Line Drawing PDF Download
