UGC DOR5983925
par Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$306.57 CAD - $306.57 CAD
$306.57 CAD
$306.57 CAD - $306.57 CAD
$306.57 CAD

Vendu en lots de : 1

Fraise-scie extra courte à 2 dents, diamètre 40 mm avec une longueur de coupe de 38 mm, une longueur totale de 130 mm et une portée de 59,5 mm avec dégagement de collet, conforme à la norme DIN 327 D avec un queue Weldon de 40 mm, HSS-E métallurgie des poudres avec finition brillante, hélice à 30° et angle de coupe à 12° pour le fraisage d'épaulement, le fraisage de rainures et le surfaçage en pente dans l'acier de décolletage et le cuivre ou les alliages de cuivre

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)C11040.0
GradeLumineux
Product Number5983925
Product FamilyC110
Insert Geometry
Depth of Cut Max — in (APMX)1.4961"
Depth of Cut Max — mm (APMX)38.0 mm
Dimensions
Cutting Diameter — in (DC)1.5748"
Cutting Diameter — mm (DC)40.0 mm
Overall Length — in (OAL)5.1181"
Overall Length — mm (OAL)130.0 mm
Usable Length — mm (LU)59.5 mm
Connection Dia. — in (DCON)1.5748"
Connection Dia. — mm (DCON)40.0 mm
Number of Flutes (NOF)2
Helix Angle (FHA)30.0°
Tool Information
ShankQueue Weldon DIN 1835B
StandardDIN 327 D
Reference Numbers
EDP Number629000
EAN7320760629000
Material Group Suitability
P — Steel and Cast Steel Usage principal
M — Stainless Steel Utilisation possible
K — Cast Iron Utilisation possible
N — Non-Ferrous Metals Usage principal
S — High Temperature Alloys Usage principal
File Type Download
C11040.0 — Line Drawing PDF Download
