R18CON77
R18CON77

R18CON77

UGC PRE5997837
par Precision Twist Drill
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$5.39 CAD - $5.39 CAD
$5.39 CAD
$5.39 CAD - $5.39 CAD
$5.39 CAD

Vendu en lots de : 12

Foret hélice normale à queue cylindrique, diamètre 0,0180" (N77), longueur totale 7/8" et longueur de coupe 3/16", conforme à la norme NAS907 Type J avec pointe en croix renforcée à 135°, en HSS-E à base de cobalt avec finition bronze pour un perçage 4xD sans débourrage dans l'acier, l'acier inoxydable, la fonte et les superalliages

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)R18CON77
GradeBronze
Product Number5997837
Product FamilyR18CO
Dimensions
Cutting Diameter — in (DC)0.018"
Cutting Diameter — mm (DC)0.46 mm
Overall Length — in (OAL)0.875"
Overall Length — mm (OAL)22.23 mm
Flute Length — in (LCF)0.1875"
Flute Length — mm (LCF)4.76 mm
Length × Diameter Ratio4
Connection Dia. — in (DCON)0.018"
Connection Dia. — mm (DCON)0.46 mm
Drill Point Angle (SIG)135°
Tool Information
ShankQueue cylindrique
Direction of ToolD'accord
StandardNAS907
Reference Numbers
EDP Number18377
File Type Download
R18CON77 — 3D Model STP Download
R18CON77 — Line Drawing PDF Download
