R18CON78
R18CON78

R18CON78

UGC PRE5997840
par Precision Twist Drill
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$5.39 CAD - $5.39 CAD
$5.39 CAD
$5.39 CAD - $5.39 CAD
$5.39 CAD

Vendu en lots de : 12

Foret court avec queue cylindrique, diamètre 0,0160" (N78) avec une longueur totale de 7/8" et une longueur de coupe de 3/16" selon la norme NAS907 Type J avec pointe hélicoïdale 135° renforcée, HSS-E au cobalt avec finition bronze pour un perçage 4xD sans débourrage dans l'acier, l'acier inoxydable, la fonte et les superalliages

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)R18CON78
GradeBronze
Product Number5997840
Product FamilyR18CO
Dimensions
Cutting Diameter — in (DC)0.016"
Cutting Diameter — mm (DC)0.41 mm
Overall Length — in (OAL)0.875"
Overall Length — mm (OAL)22.23 mm
Flute Length — in (LCF)0.1875"
Flute Length — mm (LCF)4.76 mm
Length × Diameter Ratio4
Connection Dia. — in (DCON)0.016"
Connection Dia. — mm (DCON)0.41 mm
Drill Point Angle (SIG)135°
Tool Information
ShankQueue cylindrique
Direction of ToolD'accord
StandardNAS907
Reference Numbers
EDP Number18378
File Type Download
R18CON78 — 3D Model STP Download
R18CON78 — Line Drawing PDF Download
