A002S2.0
A002S2.0
A002S2.0
A002S2.0

A002S2.0

UGC DOR6524831
par Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$5.53 CAD - $5.53 CAD
$5.53 CAD
$5.53 CAD - $5.53 CAD
$5.53 CAD

Vendu en lots de : 1

Forets courts à queue cylindrique, diamètre 2 mm, longueur totale 49 mm et longueur utile 24 mm selon la norme DIN 338 avec une pointe à 118° à affûtage en croix, en acier rapide avec revêtement TiN-tip pour perçage 4xD sans débourrage dans l'acier, fournis en blister de 2 pièces

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)A002S2.0
GradeBrillant/TiN
Product Number6524831
Product FamilyA002S
Dimensions
Cutting Diameter — in (DC)0.0787"
Cutting Diameter — mm (DC)2.0 mm
Overall Length — in (OAL)1.9291"
Overall Length — mm (OAL)49.0 mm
Flute Length — in (LCF)0.9449"
Flute Length — mm (LCF)24.0 mm
Length × Diameter Ratio4
Connection Dia. — in (DCON)0.0787"
Connection Dia. — mm (DCON)2.0 mm
Drill Point Angle (SIG)118°
Tool Information
ShankQueue cylindrique
Direction of ToolD'accord
StandardDIN 338
Reference Numbers
EDP Number46524831
EAN7320760673539
File Type Download
A002S2.0 — 3D Model STP Download
A002S2.0 — Line Drawing PDF Download
