A002S2.5
A002S2.5
A002S2.5
A002S2.5

A002S2.5

UGC DOR6524832
par Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$6.16 CAD - $6.16 CAD
$6.16 CAD
$6.16 CAD - $6.16 CAD
$6.16 CAD

Vendu en lots de : 1

Foret hélicoïdal avec queue cylindrique, diamètre 2,5 mm, longueur totale 57 mm, longueur utile 30 mm selon la norme DIN 338, pointe auto-centrante à 118°, HSS avec revêtement TiN en bout pour un perçage sans débourrage jusqu'à 4xD dans l'acier, livré sous blister de 2 pièces

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)A002S2.5
GradeBrillant/TiN
Product Number6524832
Product FamilyA002S
Dimensions
Cutting Diameter — in (DC)0.0984"
Cutting Diameter — mm (DC)2.5 mm
Overall Length — in (OAL)2.2441"
Overall Length — mm (OAL)57.0 mm
Flute Length — in (LCF)1.1811"
Flute Length — mm (LCF)30.0 mm
Length × Diameter Ratio4
Connection Dia. — in (DCON)0.0984"
Connection Dia. — mm (DCON)2.5 mm
Drill Point Angle (SIG)118°
Tool Information
ShankTige cylindrique
Direction of ToolD'accord
StandardDIN 338
Reference Numbers
EDP Number46524832
EAN7320760673546
File Type Download
A002S2.5 — 3D Model STP Download
A002S2.5 — Line Drawing PDF Download
