A002S3.0
A002S3.0
A002S3.0
A002S3.0

A002S3.0

UGC DOR6524833
par Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$5.84 CAD - $5.84 CAD
$5.84 CAD
$5.84 CAD - $5.84 CAD
$5.84 CAD

Vendu en lots de : 1

Foret de longueur jobber à queue cylindrique, diamètre 3mm avec une longueur totale de 61mm et une longueur de coupe de 33mm selon la norme DIN 338 avec une pointe fendue modifiée à 118°, HSS avec revêtement de pointe TiN pour perçage 4xD sans débourrage dans l'acier fourni en blister de 2 pièces

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)A002S3.0
GradeBrillant/TiN
Product Number6524833
Product FamilyA002S
Dimensions
Cutting Diameter — in (DC)0.1181"
Cutting Diameter — mm (DC)3.0 mm
Overall Length — in (OAL)2.4016"
Overall Length — mm (OAL)61.0 mm
Flute Length — in (LCF)1.2992"
Flute Length — mm (LCF)33.0 mm
Length × Diameter Ratio4
Connection Dia. — in (DCON)0.1181"
Connection Dia. — mm (DCON)3.0 mm
Drill Point Angle (SIG)118°
Tool Information
ShankQueue cylindrique
Direction of ToolD'accord
StandardDIN 338
Reference Numbers
EDP Number46524833
EAN7320760673553
File Type Download
A002S3.0 — 3D Model STP Download
A002S3.0 — Line Drawing PDF Download
