UGC DOR6524834
par Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$5.07 CAD - $5.07 CAD
$5.07 CAD
$5.07 CAD - $5.07 CAD
$5.07 CAD

Vendu en lots de : 1

Foret court avec queue cylindrique, diamètre 0,1250" (1/8) avec une longueur totale de 65mm et une longueur de coupe de 36mm selon la norme DIN 338 avec une pointe à 118° affûtée en croix, HSS avec revêtement TiN en pointe pour un perçage 4xD sans débourrage dans l'acier, fourni en blister de 2 pièces

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)A002S1/8
GradeBrillant/TiN
Product Number6524834
Product FamilyA002S
Dimensions
Cutting Diameter — in (DC)0.125"
Cutting Diameter — mm (DC)3.18 mm
Cutting Diameter — Fractional1/8
Overall Length — in (OAL)2.5591"
Overall Length — mm (OAL)65.0 mm
Flute Length — in (LCF)1.4173"
Flute Length — mm (LCF)36.0 mm
Length × Diameter Ratio4
Connection Dia. — in (DCON)0.1252"
Connection Dia. — mm (DCON)3.18 mm
Drill Point Angle (SIG)118°
Tool Information
ShankTige cylindrique
Direction of ToolD'accord
StandardDIN 338
Reference Numbers
EDP Number46524834
EAN7320760673560
File Type Download
A002S1/8 — 3D Model STP Download
A002S1/8 — Line Drawing PDF Download
