A002S3.2
A002S3.2
A002S3.2
A002S3.2

A002S3.2

UGC DOR6524835
par Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$6.17 CAD - $6.17 CAD
$6.17 CAD
$6.17 CAD - $6.17 CAD
$6.17 CAD

Vendu en lots de : 1

Foret de longueur jobber à queue cylindrique, diamètre 3,2 mm, longueur totale 65 mm et longueur de coupe 36 mm selon la norme DIN 338, pointe fendue modifiée à 118°, HSS avec revêtement en TiN pour un perçage 4xD sans débourrage dans l'acier, fourni sous blister de 2 pièces

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)A002S3.2
GradeBrillant/TiN
Product Number6524835
Product FamilyA002S
Dimensions
Cutting Diameter — in (DC)0.126"
Cutting Diameter — mm (DC)3.2 mm
Overall Length — in (OAL)2.5591"
Overall Length — mm (OAL)65.0 mm
Flute Length — in (LCF)1.4173"
Flute Length — mm (LCF)36.0 mm
Length × Diameter Ratio4
Connection Dia. — in (DCON)0.126"
Connection Dia. — mm (DCON)3.2 mm
Drill Point Angle (SIG)118°
Tool Information
ShankQueue cylindrique
Direction of ToolD'accord
StandardDIN 338
Reference Numbers
EDP Number46524835
EAN7320760673577
File Type Download
A002S3.2 — 3D Model STP Download
A002S3.2 — Line Drawing PDF Download
