A002S3.3
A002S3.3
A002S3.3
A002S3.3

A002S3.3

UGC DOR6524836
par Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$6.39 CAD - $6.39 CAD
$6.39 CAD
$6.39 CAD - $6.39 CAD
$6.39 CAD

Vendu en lots de : 1

Foret série courte à queue cylindrique, diamètre 3,3 mm, longueur totale 65 mm et longueur de coupe 36 mm selon la norme DIN 338, à pointe fendue modifiée 118°, HSS avec revêtement en nitrure de titane sur la pointe pour perçage 4xD sans débourrage dans l'acier, conditionné sous blister de 2 pièces

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)A002S3.3
GradeBrillant/TiN
Product Number6524836
Product FamilyA002S
Dimensions
Cutting Diameter — in (DC)0.1299"
Cutting Diameter — mm (DC)3.3 mm
Overall Length — in (OAL)2.5591"
Overall Length — mm (OAL)65.0 mm
Flute Length — in (LCF)1.4173"
Flute Length — mm (LCF)36.0 mm
Length × Diameter Ratio4
Connection Dia. — in (DCON)0.1299"
Connection Dia. — mm (DCON)3.3 mm
Drill Point Angle (SIG)118°
Tool Information
ShankTige cylindrique
Direction of ToolD'accord
StandardDIN 338
Reference Numbers
EDP Number46524836
EAN7320760673584
File Type Download
A002S3.3 — 3D Model STP Download
A002S3.3 — Line Drawing PDF Download
