A002S5/32
A002S5/32
A002S5/32
A002S5/32

A002S5/32

UGC DOR6524838
par Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$7.99 CAD - $7.99 CAD
$7.99 CAD
$7.99 CAD - $7.99 CAD
$7.99 CAD

Vendu en lots de : 1

Foret jobber à queue cylindrique, diamètre 0,1563" (5/32) avec une longueur totale de 75mm et une longueur de coupe de 43mm selon la norme DIN 338, à pointe fendue modifiée de 118°, en HSS avec revêtement en TiN pour un perçage à 4xD sans débourrage dans l'acier, livré sous blister de 2 pièces

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)A002S5/32
GradeBrillant/TiN
Product Number6524838
Product FamilyA002S
Dimensions
Cutting Diameter — in (DC)0.1563"
Cutting Diameter — mm (DC)3.97 mm
Cutting Diameter — Fractional5/32
Overall Length — in (OAL)2.9528"
Overall Length — mm (OAL)75.0 mm
Flute Length — in (LCF)1.6929"
Flute Length — mm (LCF)43.0 mm
Length × Diameter Ratio4
Connection Dia. — in (DCON)0.1563"
Connection Dia. — mm (DCON)3.97 mm
Drill Point Angle (SIG)118°
Tool Information
ShankQueue cylindrique
Direction of ToolD'accord
StandardDIN 338
Reference Numbers
EDP Number46524838
EAN7320760673607
File Type Download
A002S5/32 — 3D Model STP Download
A002S5/32 — Line Drawing PDF Download
