UGC DOR6524863
par Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$8.37 CAD - $8.37 CAD
$8.37 CAD
$8.37 CAD - $8.37 CAD
$8.37 CAD

Vendu en lots de : 1

Foret série courte à queue cylindrique, diamètre 0,1875" (3/16) avec une longueur totale de 86 mm et une longueur de goujure de 52 mm selon la norme DIN 338 avec une pointe fendue modifiée de 118°, en HSS avec revêtement TiN pour le perçage jusqu'à 4xD sans débourrage dans l'acier, fourni sous blister de 2 pièces

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)A002S3/16
GradeLumineux/TiN
Product Number6524863
Product FamilyA002S
Dimensions
Cutting Diameter — in (DC)0.1875"
Cutting Diameter — mm (DC)4.76 mm
Cutting Diameter — Fractional3/16
Overall Length — in (OAL)3.3858"
Overall Length — mm (OAL)86.0 mm
Flute Length — in (LCF)2.0472"
Flute Length — mm (LCF)52.0 mm
Length × Diameter Ratio4
Connection Dia. — in (DCON)0.1874"
Connection Dia. — mm (DCON)4.76 mm
Drill Point Angle (SIG)118°
Tool Information
ShankQueue cylindrique
Direction of ToolD'accord
StandardDIN 338
Reference Numbers
EDP Number46524863
EAN7320760673652
File Type Download
A002S3/16 — 3D Model STP Download
A002S3/16 — Line Drawing PDF Download
