A002S5/16
A002S5/16
A002S5/16
A002S5/16

A002S5/16

UGC DOR6524875
par Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$10.57 CAD - $10.57 CAD
$10.57 CAD
$10.57 CAD - $10.57 CAD
$10.57 CAD

Vendu en lots de : 1

Foret série courte à queue cylindrique, diamètre 0,3125" (5/16) avec une longueur totale de 117mm et une longueur de coupe de 75mm selon la norme DIN 338 avec une pointe auto-centrante à 118°, HSS avec revêtement TiN-tip pour perçage 4xD sans débourrage dans l'acier, fourni sous blister individuel

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)A002S5/16
GradeBrillant/TiN
Product Number6524875
Product FamilyA002S
Dimensions
Cutting Diameter — in (DC)0.3125"
Cutting Diameter — mm (DC)7.94 mm
Cutting Diameter — Fractional16 mai
Overall Length — in (OAL)4.6063"
Overall Length — mm (OAL)117.0 mm
Flute Length — in (LCF)2.9528"
Flute Length — mm (LCF)75.0 mm
Length × Diameter Ratio4
Connection Dia. — in (DCON)0.3126"
Connection Dia. — mm (DCON)7.94 mm
Drill Point Angle (SIG)118°
Tool Information
ShankQueue cylindrique
Direction of ToolD'accord
StandardDIN 338
Reference Numbers
EDP Number46524875
EAN7320760673775
File Type Download
A002S5/16 — 3D Model STP Download
A002S5/16 — Line Drawing PDF Download
