TPG 221 T00420:TC100

TPG 221 T00420:TC100

UGC DOR6755450
par Dormer Pramet
Primary Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$24.96 CAD - $24.96 CAD
$24.96 CAD
$24.96 CAD - $24.96 CAD
$24.96 CAD

Vendu en lots de : 10

Plaquette simple face à arête triangulaire avec dépouille de 11° et diamètre du cercle inscrit de 1/4", épaisseur de 1/8", rayon de bec de 1/64", précision d'indexage selon la classe de tolérance ISO-G, arêtes de coupe avec facette brise-copeaux en T de -20°/0.004", en nuance TC100, une céramique non revêtue dans la plage ISO K01-K15, pour l'usinage grande vitesse des fontes

For more information about this product, click here

Identification
Ordering Code (ANSI)TPG 221 T00420:TC100
Product Name (ISO)TPGN 110304 T01020:TC100
GradeTC100
Chipbreaker (CBMD)Pas de brise-copeaux
Product Number6755450
Product FamilyTPGN CER
Insert Geometry
Insert DesignPGNT
Insert Shape Code (SC)T - angle de 60° inclus
Insert Geometry
Inscribed Circle Dia. — in (IC)0.25"
Inscribed Circle Dia. — mm (IC)6.35 mm
Insert Thickness — in (S)0.125"
Insert Thickness — mm (S)3.18 mm
Corner Radius — in (RE)0.016"
Corner Radius — mm (RE)0.4 mm
Depth of Cut Max — in (APMX)0.102"
Depth of Cut Max — mm (APMX)2.6 mm
Tool Information
Reference Numbers
EDP Number6755450
EAN3603602908162
File Type Download
TPG 221 T00420:TC100 — Line Drawing PDF Download
