ADKX 15T308ER-F:M8345
ADKX 15T308ER-F:M8345

ADKX 15T308ER-F:M8345

UGC DOR6756225
par Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$18.94 CAD - $18.94 CAD
$18.94 CAD
$18.94 CAD - $18.94 CAD
$18.94 CAD

Vendu en lots de : 10

Plaquette de fraisage simple face ADKX 15T3, parallélogramme 85° pour une profondeur de coupe maximale de 10 mm, avec rayon de bec de 0,8 mm, une précision de positionnement selon la classe de tolérance ISO-K et géométrie F à arêtes vives adoucies, carbure WC-Co revêtu PVD M8345 dans les plages de nuances ISO P30-P50/M30-M40 et S20-S30 pour l'usinage de l'acier, de l'acier inoxydable et des superalliages avec les fraises à épaulement CAD15

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)ADKX 15T308ER-F:M8345
GradeM8345
Chipbreaker (CBMD)F
Product Number6756225
Product FamilyADKX 15
Insert Geometry
Insert DesignADKX
Insert Shape Code (SC)A - parallélogramme angle inclus de 85°
Insert Thickness — in (S)0.156"
Insert Thickness — mm (S)3.97 mm
Corner Radius — in (RE)0.031"
Corner Radius — mm (RE)0.8 mm
Depth of Cut Max — in (APMX)0.394"
Depth of Cut Max — mm (APMX)10.0 mm
Tool Information
Reference Numbers
EDP Number6756225
EAN3603602915917
Material Group Suitability
P — Steel and Cast Steel Utilisation possible
M — Stainless Steel Usage principal
S — High Temperature Alloys Utilisation possible
File Type Download
ADKX 15T308ER-F:M8345 — Line Drawing PDF Download
