ZP 10ER-FM:M8310
ZP 10ER-FM:M8310

ZP 10ER-FM:M8310

UGC DOR6756238
par Dormer Pramet
Primary Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$40.67 CAD - $40.67 CAD
$40.67 CAD
$40.67 CAD - $40.67 CAD
$40.67 CAD

Vendu en lots de : 10

Plaquette indexable à bout sphérique pour un diamètre de 10 mm (0,3937") pour une profondeur de coupe maximale de 8,9 mm (0,3504"), géométrie FM et carbure WC-Co à grain fin revêtu PVD M8310, dans les plages de nuances ISO P01-P10 et K01-K10 pour l'usinage de l'acier et de la fonte avec des fraises à copier L2-SZPshoulder mills SLN12X

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)ZP 10ER-FM:M8310
GradeM8310
Chipbreaker (CBMD)FM
Product Number6756238
Product FamilyPZ
Insert Geometry
Insert DesignPZ
Insert Shape Code (SC)X - Conception spéciale
Insert Thickness — in (S)0.067"
Insert Thickness — mm (S)1.7 mm
Depth of Cut Max — in (APMX)0.35"
Depth of Cut Max — mm (APMX)8.9 mm
Tool Information
Reference Numbers
EDP Number6756238
EAN3603602916044
File Type Download
ZP 10ER-FM:M8310 — Line Drawing PDF Download
