UGC DOR6757031
par Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$1,647.00 CAD - $1,647.00 CAD
$1,647.00 CAD
$1,647.00 CAD - $1,647.00 CAD
$1,647.00 CAD

Vendu en lots de : 1

Fraise à épaule à géométrie positive/négative utilisant 9 plaquettes unilatérales APKT 1604.. ou APET 1604.., diamètre de coupe 125 mm avec angle d'attaque de 90° et alésage de raccordement de 40 mm selon DIN 8030-B, longueur de dépassement de 63 mm et pas différentiel pour le surfaçage d'épaulements peu profonds, le fraisage de rainures peu profondes, le fraisage en rampe, le fraisage hélicoïdal, le fraisage en plongée et le fraisage en plongée progressive avec une profondeur de coupe maximale de 13,0 mm

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)125B9R-S90AP16D
Product Number6757031
Product FamilySAP16D
Insert Geometry
Depth of Cut Max — mm (APMX)13.0 mm
Dimensions
Cutting Diameter — in (DC)4.921"
Cutting Diameter — mm (DC)125.0 mm
Overall Length — in (OAL)2.48"
Overall Length — mm (OAL)63.0 mm
Functional Length — mm (LF)63.0 mm
Connection Dia. — in (DCON)1.575"
Connection Dia. — mm (DCON)40.0 mm
Number of Flutes (NOF)9
Tool Information
Tool DesignSAP16D
ShankFraise hémisphérique DIN 8030 B
Direction of ToolNeutre
Reference Numbers
EDP Number6757031
EAN3603602923974
File Type Download
125B9R-S90AP16D — Line Drawing PDF Download
