RCMX 3209MO-RM2:T5315
RCMX 3209MO-RM2:T5315

RCMX 3209MO-RM2:T5315

UGC DOR6802056
par Dormer Pramet
Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$92.86 CAD - $92.86 CAD
$92.86 CAD
$92.86 CAD - $92.86 CAD
$92.86 CAD

Vendu en lots de : 5

Plaquette de tournage positive à conception spéciale, ronde, avec un dépouille de 7°, un diamètre de 32 mm, une épaisseur de 9,52 mm, une précision de positionnement conforme à la classe de tolérance ISO M, un brise-copeaux RM2, en nuance T5315, un carbure WC-Co revêtu MT-CVD dans la gamme ISO K10-K25, pour l'usinage lourd à moyen des fontes

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)RCMX 3209MO-RM2:T5315
GradeT5315
Chipbreaker (CBMD)RM2
Product Number6802056
Product FamilyRCMX
Insert Geometry
Insert DesignRCMX
Insert Shape Code (SC)R - rond
Insert Thickness — in (S)0.375"
Insert Thickness — mm (S)9.53 mm
Depth of Cut Max — in (APMX)0.315"
Depth of Cut Max — mm (APMX)8.0 mm
Tool Information
Reference Numbers
EDP Number6802056
EAN3603602992888
File Type Download
RCMX 3209MO-RM2:T5315 — Line Drawing PDF Download
