VCGT 1.21.50.5-SF3:H07
VCGT 1.21.50.5-SF3:H07

VCGT 1.21.50.5-SF3:H07

UGC DOR7168590
par Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$17.61 CAD - $17.61 CAD
$17.61 CAD
$17.61 CAD - $17.61 CAD
$17.61 CAD

Vendu en lots de : 10

Plaquette de tournage positive simple face, rhomboïde à 35° avec dépouille de 7°, diamètre du cercle inscrit de 5/32", épaisseur de 3/32", rayon de bec de 1/128" et précision de positionnement selon la classe de tolérance ISO G, brise-copeaux SF3, en nuance H07, un carbure WC-Co non revêtu dans les plages ISO N10 - N30 et S01 - S20, pour l'usinage fin à moyen des métaux non ferreux et des superalliages

For more information about this product, click here

Identification
Ordering Code (ANSI)VCGT 1.21.50.5-SF3:H07
Product Name (ISO)VCGT 070202E-SF3:H07
GradeH07
Chipbreaker (CBMD)SF3
Product Number7168590
Product FamilyVCGT
Insert Geometry
Insert DesignVCGT
Insert Shape Code (SC)V - angle de 35° inclus
Insert Geometry
Inscribed Circle Dia. — in (IC)0.156"
Inscribed Circle Dia. — mm (IC)3.97 mm
Insert Thickness — in (S)0.094"
Insert Thickness — mm (S)2.38 mm
Corner Radius — in (RE)0.008"
Corner Radius — mm (RE)0.2 mm
Depth of Cut Max — in (APMX)0.063"
Depth of Cut Max — mm (APMX)1.6 mm
Tool Information
Reference Numbers
EDP Number7168590
EAN3603603171862
File Type Download
VCGT 1.21.50.5-SF3:H07 — Line Drawing PDF Download
