RC 10-F:M4310
RC 10-F:M4310

RC 10-F:M4310

UGC DOR7637786
par Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$51.51 CAD - $51.51 CAD
$51.51 CAD
$51.51 CAD - $51.51 CAD
$51.51 CAD

Vendu en lots de : 10

Plaquette de fraisage à copier à bout sphérique avec un diamètre de 0,3937" pour une profondeur de coupe maximale de 0,0394", géométrie F et carbure WC-Co à grains fins revêtu PVD M4310 dans les gammes ISO K05-K15 et H05-H15 pour l'usinage de la fonte et des matériaux trempés avec des fraises à copier K2-SRC

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)RC 10-F:M4310
GradeM4310
Chipbreaker (CBMD)F
Product Number7637786
Product FamilyRC
Insert Geometry
Insert DesignRC
Insert Shape Code (SC)R - rond
Insert Thickness — in (S)0.098"
Insert Thickness — mm (S)2.5 mm
Depth of Cut Max — in (APMX)0.039"
Depth of Cut Max — mm (APMX)1.0 mm
Tool Information
Reference Numbers
EDP Number7637786
EAN3603603538498
File Type Download
RC 10-F:M4310 — Line Drawing PDF Download
