S2385/8
S2385/8

S2385/8

UGC DOR7648867
par Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$167.56 CAD - $167.56 CAD
$167.56 CAD
$167.56 CAD - $167.56 CAD
$167.56 CAD

Vendu en lots de : 1

Fraise à lamer hémisphérique de longueur standard à 4 dents, diamètre 5/8" avec une longueur de coupe de 1.1/4", une longueur totale de 3.1/2" et un rayon de profil complet de 5/16", conforme à la norme DORMER avec une queue cylindrique de 5/8", en carbure monobloc avec revêtement TiAlN, hélice à 30° pour le fraisage en copiage dans l'acier et l'acier moulé, l'acier inoxydable et la fonte

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)S2385/8
GradeTiAlN
Product Number7648867
Product FamilyS238
Insert Geometry
Corner Radius — in (RE)0.313"
Depth of Cut Max — mm (APMX)31.75 mm
Dimensions
Cutting Diameter — in (DC)0.625"
Cutting Diameter — mm (DC)15.88 mm
Cutting Diameter — Fractional5/8
Overall Length — in (OAL)3.5"
Overall Length — mm (OAL)88.9 mm
Connection Dia. — in (DCON)0.625"
Connection Dia. — mm (DCON)15.88 mm
Number of Flutes (NOF)4
Helix Angle (FHA)30.0°
Tool Information
ShankQueue cylindrique
StandardNorme de travail
Reference Numbers
EDP Number7648867
EAN7320760849149
File Type Download
S2385/8 — Line Drawing PDF Download
