S2395.0
S2395.0

S2395.0

UGC DOR7648881
par Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$31.34 CAD - $31.34 CAD
$31.34 CAD
$31.34 CAD - $31.34 CAD
$31.34 CAD

Vendu en lots de : 1

Fraise à lamer à queue cylindrique longueur normale à 4 dents, diamètre 5mm avec une longueur de coupe de 16mm, une longueur totale de 50mm et un rayon de profil complet de 2.5mm, selon la norme DORMER avec une queue de 5mm, en carbure monobloc avec revêtement TiAlN, hélice de 30° pour le fraisage en plongée dans l'acier et l'acier moulé, l'acier inoxydable et la fonte

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)S2395.0
GradeTiAlN
Product Number7648881
Product FamilyS239
Insert Geometry
Corner Radius — in (RE)0.098"
Corner Radius — mm (RE)2.5 mm
Depth of Cut Max — in (APMX)0.6299"
Depth of Cut Max — mm (APMX)16.0 mm
Dimensions
Cutting Diameter — in (DC)0.1969"
Cutting Diameter — mm (DC)5.0 mm
Overall Length — in (OAL)1.9685"
Overall Length — mm (OAL)50.0 mm
Connection Dia. — in (DCON)0.1969"
Connection Dia. — mm (DCON)5.0 mm
Number of Flutes (NOF)4
Helix Angle (FHA)30.0°
Tool Information
ShankQueue cylindrique
StandardNorme de travail
Reference Numbers
EDP Number7648881
EAN7320760849286
File Type Download
S2395.0 — Line Drawing PDF Download
