Grooving And Part Off Inserts

Top clamp grooving tool for holding a 0,984" long double ended insert with 0.118" cutting width (designation GL3-D… ), right handed with insert par...

Double ended parting and grooving insert, 25 mm long with a 3 mm cutting width and 0.2 mm corner radii, a cutting width tolerance of ±0.05 mm. Comb...

Double ended parting and grooving insert, 0.984 inch long with a 0.118 inch cutting width and 0.008 inch corner radii. Grade G8330 PVD coated fine ...

Double ended parting and grooving insert, 0.984 inch long with a 0.118 inch cutting width and 0.008 inch corner radii, 12°. Grade G8330 PVD coated ...

Single ended parting and grooving insert, with a 4.1mm cutting width and 0.2mm corner radii, an accuracy according to tolerance class-M and chip-br...

Double ended parting and grooving insert, 26 mm long with a 6 mm cutting width and 3 mm corner radii, a cutting width tolerance of ±0.05 mm. Combin...

Double ended parting and grooving insert, 26 mm long with a 5 mm cutting width and 2.5 mm corner radii, a cutting width tolerance of ±0.05 mm. Comb...

Double ended parting and grooving insert, 25 mm long with a 4 mm cutting width and 2 mm corner radii, a cutting width tolerance of ±0.05 mm. Combin...

Double ended parting and grooving insert, 25 mm long with a 3 mm cutting width and 1.5 mm corner radii, a cutting width tolerance of ±0.05 mm. Comb...

Double ended parting and grooving insert, 25 mm long with a 2 mm cutting width and 1 mm corner radii, a cutting width tolerance of ±0.05 mm. Combin...

Double ended parting and grooving insert, 25 mm long with a 6 mm cutting width and 0.8 mm corner radii, a cutting width tolerance of ±0.05 mm. Comb...

Double ended parting and grooving insert, 25 mm long with a 5 mm cutting width and 0.8 mm corner radii, a cutting width tolerance of ±0.05 mm. Comb...

Double ended parting and grooving insert, 25 mm long with a 4 mm cutting width and 0.4 mm corner radii, a cutting width tolerance of ±0.05 mm. Comb...

Double ended parting and grooving insert, 25 mm long with a 3 mm cutting width and 0.4 mm corner radii, a cutting width tolerance of ±0.05 mm. Comb...

Double ended parting and grooving insert, 25 mm long with a 2 mm cutting width and 0.2 mm corner radii, a cutting width tolerance of ±0.05 mm. Comb...

Double ended parting and grooving insert, 25 mm long with a 4 mm cutting width and 0.2 mm corner radii, a cutting width tolerance of ±0.05 mm. Comb...

Double ended parting and grooving insert, 25 mm long with a 3 mm cutting width and 0.2 mm corner radii, a cutting width tolerance of ±0.05 mm. Comb...

Double ended parting and grooving insert, 25 mm long with a 2 mm cutting width and 0.2 mm corner radii, a cutting width tolerance of ±0.05 mm. Comb...

Double ended parting and grooving insert, 25 mm long with a 4 mm cutting width and 0.2 mm corner radii, a cutting width tolerance of ±0.05 mm. Comb...

Double ended parting and grooving insert, 25 mm long with a 3 mm cutting width and 0.2 mm corner radii, a cutting width tolerance of ±0.05 mm. Comb...

Double ended parting and grooving insert, 25 mm long with a 2 mm cutting width and 0.2 mm corner radii, a cutting width tolerance of ±0.05 mm. Comb...

Single ended parting and grooving insert, 0.957 inch long with a 0.154 inch cutting width and 0.008 inch corner radii, a cutting width tolerance of...

Single ended parting and grooving insert, 0.965 inch long with a 0.118 inch cutting width and 0.008 inch corner radii, a cutting width tolerance of...

Single ended parting and grooving insert, 0.965 inch long with a 0.079 inch cutting width and 0.008 inch corner radii, a cutting width tolerance of...

Double ended parting and grooving insert, 0.984 inch long with a 0.315 inch cutting width and 0.031 inch corner radii. Grade G8330 PVD coated fine ...

Double ended parting and grooving insert, 0.65 inch long with a 0.059 inch cutting width and 0.006 inch corner radii. Grade G8330 PVD coated fine g...

Double ended parting and grooving insert, 0.65 inch long with a 0.059 inch cutting width and 0.006 inch corner radii. Grade G8330 PVD coated fine g...

Double ended parting and grooving insert, 0.65 inch long with a 0.059 inch cutting width and 0.006 inch corner radii. Grade G8330 PVD coated fine g...

Double ended parting and grooving insert, 0.65 inch long with a 0.059 inch cutting width and 0.006 inch corner radii. Grade G8330 PVD coated fine g...

Double ended parting and grooving insert, 0.65 inch long with a 0.059 inch cutting width and 0.006 inch corner radii. Grade G8330 PVD coated fine g...

GL1-S2020KFR-16-60 is external right handed tool for GL inserts. Suited for radial grooving, parting-off, turning and profiling applications. Reinf...

GL1-S2020KFL-16-60 is external left handed tool for GL inserts. Suited for radial grooving, parting-off, turning and profiling applications. Reinfo...

Single ended parting and grooving insert, 0.957 inch long with a 0.157 inch cutting width and 0.008 inch corner radii. Grade G8330 PVD coated fine ...

Single ended parting and grooving insert, 0.957 inch long with a 0.157 inch cutting width and 0.008 inch corner radii. Grade G8330 PVD coated fine ...

Single ended parting and grooving insert, 0.965 inch long with a 0.118 inch cutting width and 0.008 inch corner radii. Grade G8330 PVD coated fine ...

Single ended parting and grooving insert, 0.965 inch long with a 0.118 inch cutting width and 0.008 inch corner radii. Grade G8330 PVD coated fine ...

Double ended parting and grooving insert, 0.984 inch long with a 0.079 inch cutting width and 0.039 inch full radius. Grade T7325 MT-CVD coated fun...

Double ended parting and grooving insert, 0.984 inch long with a 0.079 inch cutting width and 0.039 inch full radius. Grade G8330 PVD coated fine g...

Double ended parting and grooving insert, 0.984 inch long with a 0.079 inch cutting width and 0.008 inch corner radii. Grade T7325 MT-CVD coated fu...

Double ended parting and grooving insert, 0.984 inch long with a 0.079 inch cutting width and 0.008 inch corner radii. Grade G8330 PVD coated fine ...

Double ended parting and grooving insert, 1.024 inch long with a 0.236 inch cutting width and 0.118 inch full radius. Grade T7325 MT-CVD coated fun...

Double ended parting and grooving insert, 1.024 inch long with a 0.236 inch cutting width and 0.118 inch full radius. Grade G8330 PVD coated fine g...

Double ended parting and grooving insert, 0.984 inch long with a 0.236 inch cutting width and 0.031 inch corner radii. Grade T7325 MT-CVD coated fu...

Double ended parting and grooving insert, 0.984 inch long with a 0.236 inch cutting width and 0.031 inch corner radii. Grade G8330 PVD coated fine ...

Double ended parting and grooving insert, 1.024 inch long with a 0.197 inch cutting width and 0.098 inch full radius. Grade T7325 MT-CVD coated fun...

Double ended parting and grooving insert, 1.024 inch long with a 0.197 inch cutting width and 0.098 inch full radius. Grade G8330 PVD coated fine g...

Double ended parting and grooving insert, 0.984 inch long with a 0.197 inch cutting width and 0.031 inch corner radii. Grade T7325 MT-CVD coated fu...
