160C07R-SMORC20-C

160C07R-SMORC20-C

SKU DOR7155926
by Dormer Pramet
Primary Use: Possible Use:
Availability in Distribution Centers:
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)
For more information about this product, click here
$1,098.00 - $1,098.00
$1,098.00
$1,098.00 - $1,098.00
$1,098.00

Sold in packs of: 1

Copy face mill with double negative geometry which utilises 7 off RCMT 2006MO.. single-sided inserts, cutting diameter 160mm with 40mm connection bore according to DIN 8030-C, 63mm protrusion length, through coolant for face milling, copy milling, ramping, helical milling and progressive plunge milling with a maximum depth of cut of 10.0mm

For more information about this product, click here

Identification
Ordering Code (ANSI/ISO)160C07R-SMORC20-C
Product Number7155926
Product FamilySRC20
Insert Geometry
Depth of Cut Max — mm (APMX)2.9 mm
Dimensions
Cutting Diameter — in (DC)5.512"
Cutting Diameter — mm (DC)140.0 mm
Functional Length — mm (LF)63.0 mm
Connection Dia. — in (DCON)1.575"
Connection Dia. — mm (DCON)40.0 mm
Number of Flutes (NOF)7
Tool Information
Tool DesignSRC20
ShankShell mill DIN 8030 C
Direction of ToolRight
Through Coolant Yes
Reference Numbers
EDP Number7155926
EAN3603603162129
File Type Download
160C07R-SMORC20-C — 3D Model STP Download
160C07R-SMORC20-C — 2D Model DXF Download
160C07R-SMORC20-C — Line Drawing PDF Download
