E0385/16

E0385/16

by Dormer Pramet
Primary Use: P - Steel and Cast Steel Possible Use: M - Stainless Steel

Spiral flute tap with chamfer form C with a 2-3xP plug lead, for Unified National Fine thread UNF 5/16" with 24 TPI and 3B class of fit with H3 pitch diameter limits, dimensions according to ANSI standard with 0.3180" shank and 0.2380" square drive, powder metallurgical HSS-E with steam tempered surface finish and 45° helix angle for 2.5xD blind hole threading in general purpose applications

Inventory
🔗 Check Stock - ADC Warehouse (1-4 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)

Sold in packs of: 1

For more information about this product, click here
$32.01 - $32.01
$32.01 - $32.01
$32.01
$32.01 - $32.01
$32.01
Enjoy same-day shipping on orders placed before 2:30 PM MST. For in stock items, please refer to our shipping page for rates and transit times. If in a stocking warehouse, your order will arrive within the estimated delivery timeframe displayed above.

In the event of a delay, our customer service team will contact you with updated details and provide the option to cancel if the product cannot be delivered within the expected timeframe.

Material: HSS-E-PM

Lenxth x Diameter Ratio: 2.5

Overall Length (OAL): 2.7188

Connetion Diameter: 0.318

Tool Direction: Right

Diameter Size: 5/16

TPI: 24.0

Thread Form: UNF - Unified Fine

Shank: Cylindrical shank with Square

Usable Length: 1.3094

Grade: Steam Tempered

EDP: 582459

EAN: 7320760582459

MFG Part Number: 5973856
