A10023/64

A10023/64

SKU DOR5966986
by Dormer Pramet
Primary Use: Possible Use:

Jobber length drill with straight shank, diameter 0.3594" (23/64) with an overall length of 125mm and flute length of 81mm according to DIN 338 standard with 118° point angle, HSS with steam tempered finish for 4xD drilling without pecking in steel

Inventory
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)

Sold in packs of: 10

For more information about this product, click here
$10.34 - $10.34
$10.34
$10.34 - $10.34
$10.34
For in stock items, please refer to our shipping page for rates and transit times. If in a stocking warehouse, your order will arrive within the estimated delivery timeframe displayed above.

In the event of a delay, our customer service team will contact you with updated details and provide the option to cancel if the product cannot be delivered within the expected timeframe.

Material: HSS

Cutting Diameter - in (DC): 0.3594

Cutting Diameter - mm (DC): 9.13

Drill Point Angle - deg: 118

Flute Length: 3.189

Lenxth x Diameter Ratio: 4

Overall Length (OAL): 4.9213

Connetion Diameter: 0.3594

Tool Direction: Right

Shank: Cylindrical shank

Fractional: 23/64

Grade: Steam Tempered

EDP: 1561

EAN: 7320760001561

MFG Part Number: 5966986
