A5103.8

A5103.8

SKU DOR5970453
by Dormer Pramet
Primary Use: Possible Use:

Jobber length ADX drill with straight shank, diameter 3.8mm with an overall length of 75mm and flute length of 43mm according to DIN 338 standard with 130° volute point, HSS with TiN coating for 4xD drilling without pecking in steel, stainless steel, cast iron and non-ferrous material

Inventory
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)

Sold in packs of: 1

For more information about this product, click here
$24.66 - $24.66
$24.66
$24.66 - $24.66
$24.66
For in stock items, please refer to our shipping page for rates and transit times. If in a stocking warehouse, your order will arrive within the estimated delivery timeframe displayed above.

In the event of a delay, our customer service team will contact you with updated details and provide the option to cancel if the product cannot be delivered within the expected timeframe.

Material: HSS

Cutting Diameter - in (DC): 0.1496

Cutting Diameter - mm (DC): 3.8

Drill Point Angle - deg: 130

Flute Length: 1.6929

Lenxth x Diameter Ratio: 4

Overall Length (OAL): 2.9528

Connetion Diameter: 0.1496

Tool Direction: Right

Shank: Cylindrical shank

Grade: TiN

EDP: 36570

EAN: 7320760036570

MFG Part Number: 5970453
