G1296.0

G1296.0

SKU DOR5973328
by Dormer Pramet
Primary Use: Possible Use:

Countersink with 1-flute, 90° chamfering angle, maximum diameter 6.00mm with an overall length of 45mm and 6mm straight shank, according to DORMER standard to produce a conical seat for ISO Metric countersunk-head screws, HSS with standard bright finish for machining free machining and plain carbon steel, wrought and copper or copper alloys

Inventory
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)

Sold in packs of: 1

For more information about this product, click here
$22.83 - $22.83
$22.83
$22.83 - $22.83
$22.83
For in stock items, please refer to our shipping page for rates and transit times. If in a stocking warehouse, your order will arrive within the estimated delivery timeframe displayed above.

In the event of a delay, our customer service team will contact you with updated details and provide the option to cancel if the product cannot be delivered within the expected timeframe.

Material: HSS

Cutting Diameter - in (DC): 0.2362

Cutting Diameter - mm (DC): 6.0

Drill Point Angle - deg: 90

Overall Length (OAL): 1.7717

Connetion Diameter: 0.2362

Tool Direction: Right

Shank: Cylindrical shank

Grade: Bright

EDP: 149195

EAN: 7320760149195

MFG Part Number: 5973328
