E0411/4

E0411/4

SKU DOR5973924
by Dormer Pramet
Primary Use: Possible Use:

Spiral point tap with chamfer form B with a 3.5-5xP second lead, for British Standard Pipe thread G 1/4" with 19 TPI and Normal class of fit, dimensions according to DORMER-ISO standard with 10.0mm shank and 8.0mm square drive, powder metallurgical HSS-E with steam tempered surface finish for 2.5xD through hole threading in general purpose applications

Inventory
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)

Sold in packs of: 1

For more information about this product, click here
$64.23 - $64.23
$64.23
$64.23 - $64.23
$64.23
For in stock items, please refer to our shipping page for rates and transit times. If in a stocking warehouse, your order will arrive within the estimated delivery timeframe displayed above.

In the event of a delay, our customer service team will contact you with updated details and provide the option to cancel if the product cannot be delivered within the expected timeframe.

Material: HSS-E-PM

Lenxth x Diameter Ratio: 2.5

Overall Length (OAL): 3.937

Connetion Diameter: 0.3937

Tool Direction: Right

Diameter Size: 1/4

Thread Diameter - in: 0.518

Thread Diameter - mm: 13.157

TPI: 19.0

Thread Form: G - British standard pipe fastening - G series

Shank: Cylindrical shank with Square

Grade: Steam Tempered

EDP: 569825

EAN: 7320760569825

MFG Part Number: 5973924
