E250M48

E250M48

SKU DOR5975848
by Dormer Pramet
Primary Use: Possible Use:

Straight flute tap, for ISO-Metric thread M48 with 5.00 mm pitch and 6H class of fit, dimensions according to DIN 376 standard with 36.0mm shank and 29.0mm square drive, powder metallurgical HSS-E with bright finish for 1.5xD through or blind hole threading in free machining and plain carbon steel

Inventory
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)

Sold in packs of: 1

For more information about this product, click here
$677.34 - $677.34
$677.34
$677.34 - $677.34
$677.34
For in stock items, please refer to our shipping page for rates and transit times. If in a stocking warehouse, your order will arrive within the estimated delivery timeframe displayed above.

In the event of a delay, our customer service team will contact you with updated details and provide the option to cancel if the product cannot be delivered within the expected timeframe.

Material: HSS-E

Lenxth x Diameter Ratio: 1.5

Overall Length (OAL): 9.8425

Connetion Diameter: 1.4173

Tool Direction: Right

Diameter Size: 48

Pitch - mm: 5.0

Pitch - in: 0.1969

Thread Form: M - Metric coarse

Shank: Cylindrical shank with Square

Grade: Bright

EDP: 87121

EAN: 7320760087121

MFG Part Number: 5975848
