E5245/16NO1

E5245/16NO1

SKU DOR5976098
by Dormer Pramet
Primary Use: Possible Use:

Straight flute hand tap NO1 with a 6-8xP taper lead, for Unified National Fine thread UNF 5/16" with 24 TPI and 2B class of fit, dimensions according to ISO 529 standard with 8.0mm shank and 6.3mm square drive, HSS with bright finish for 1.5xD through or blind hole threading in free machining and plain carbon steel and copper or copper alloys

Inventory
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)

Sold in packs of: 1

For more information about this product, click here
$24.59 - $24.59
$24.59
$24.59 - $24.59
$24.59
For in stock items, please refer to our shipping page for rates and transit times. If in a stocking warehouse, your order will arrive within the estimated delivery timeframe displayed above.

In the event of a delay, our customer service team will contact you with updated details and provide the option to cancel if the product cannot be delivered within the expected timeframe.

Material: HSS

Lenxth x Diameter Ratio: 1.5

Overall Length (OAL): 2.8346

Connetion Diameter: 0.315

Tool Direction: Right

Diameter Size: 5/16

Thread Diameter - in: 0.3125

Thread Diameter - mm: 7.938

TPI: 24.0

Thread Form: UNF - Unified Fine

Shank: Cylindrical shank with Square

Usable Length: 1.1417

Grade: Bright

EDP: 153499

EAN: 7320760153499

MFG Part Number: 5976098
