R45427/64

R45427/64

SKU DOR5979843
by Dormer Pramet
Primary Use: Possible Use:

High-performance FORCE X drill with DIN 6535HA NC parallel shank, diameter 0.4219" (27/64) with an overall length of 118mm and flute length of 70mm according to DIN 6537 L standard with 140° modified 4-facet split point, solid carbide with TiAlN coating and continiously thinned parallel web for 5xD drilling without pecking in steel, stainless steel, cast iron, non-ferrous material and hardened material

Inventory
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)

Sold in packs of: 1

For more information about this product, click here
$212.14 - $212.14
$212.14
$212.14 - $212.14
$212.14
For in stock items, please refer to our shipping page for rates and transit times. If in a stocking warehouse, your order will arrive within the estimated delivery timeframe displayed above.

In the event of a delay, our customer service team will contact you with updated details and provide the option to cancel if the product cannot be delivered within the expected timeframe.

Material: HM

Cutting Diameter - in (DC): 0.4219

Cutting Diameter - mm (DC): 10.72

Drill Point Angle - deg: 140

Flute Length: 2.7559

Through Coolant: 0

Lenxth x Diameter Ratio: 5

Overall Length (OAL): 4.6457

Connetion Diameter: 0.4724

Tool Direction: Right

Shank: Cylindrical shank DIN 6535 HA

Fractional: 27/64

Grade: TiAlN

EDP: 624197

EAN: 7320760624197

MFG Part Number: 5979843
