C1101

C1101

SKU DOR5983749
by Dormer Pramet
Primary Use: Possible Use:

Extra short series slot drill with 2 flutes, diameter 1" with 26mm length of cut 102mm overall length and 45.5mm reach with neck relief, according to DIN 327 D standard with a 25mm Weldon shank, powder metallurgical HSS-E with bright finish, 30° helix and 12° rake angle for shoulder milling, slot milling and ramping in free machining steel and copper or copper alloys

Inventory
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)

Sold in packs of: 1

For more information about this product, click here
$154.87 - $154.87
$154.87
$154.87 - $154.87
$154.87
For in stock items, please refer to our shipping page for rates and transit times. If in a stocking warehouse, your order will arrive within the estimated delivery timeframe displayed above.

In the event of a delay, our customer service team will contact you with updated details and provide the option to cancel if the product cannot be delivered within the expected timeframe.

Material: HSS-E-PM

Coating: Bright

Cutting Diameter - in (DC): 1.0

Cutting Diameter - mm (DC): 25.4

Overall Length (OAL): 4.0157

Connetion Diameter: 0.9843

Max. Depth of Cut: 1.0236

Shank: Weldon shank DIN 1835B

Fractional: 1''

Steel and Cast Steel: Primary use

Stainless Steel: Possible use

Cast Iron: Possible use

Non Ferrous: Primary use

High Temp Alloys: Primary use

Grade: Bright

Cutting Edge Count: 2

EDP: 621929

EAN: 7320760639955

MFG Part Number: 5983749
