ADKX 15T308ER-F:M8345

ADKX 15T308ER-F:M8345

SKU DOR6756225
by Dormer Pramet
Primary Use: Possible Use:

Single-sided milling insert ADKX 15T3, 85° parallelogram for a maximum depth of cut of .3937", with .0315" corner radius, an indexing accuracy according to ISO-tolerance class-K and F geometry with rounded cutting edges, M8345 PVD coated WC-Co carbide within ISO-grade ranges P30-P50/M30-M40 and S20-S30 for machining of steel, stainless-steel and superalloy with shoulder mills CAD15

Inventory
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)

Sold in packs of: 10

For more information about this product, click here
$16.71 - $16.71
$16.71
$16.71 - $16.71
$16.71
Enjoy same-day shipping on orders placed before 2:30 PM MST. For in stock items, please refer to our shipping page for rates and transit times. If in a stocking warehouse, your order will arrive within the estimated delivery timeframe displayed above.

In the event of a delay, our customer service team will contact you with updated details and provide the option to cancel if the product cannot be delivered within the expected timeframe.

Max. Depth of Cut: 0.394

Insert Design: ADKX

Insert Shape Code: A - parallelogram 85° included angle

Insert Thickness: 0.156

Steel and Cast Steel: Possible use

Stainless Steel: Primary use

High Temp Alloys: Possible use

Chip Breaker: F

Grade: M8345

Corner Radius - in: 0.031

Corner Radius - mm: 0.8

EDP: 6756225

EAN: 3603602915917

MFG Part Number: 6756225
