315K10N-S90XN16N30
SKU DOR6760158
Primary Use:
Possible Use:
Disc mill with positve/negative geometry which utilises 20 off XNHQ 1606.. double-sided inserts, cutting diameter 315mm with 90° approach angle and 60mm connection bore according to DIN 8030, for deep slot milling with a width of cut of 24,5 ÷ 30,5mm
Inventory
Sold in packs of: 1
For more information about this product,
click here
Original price
$6,729.00
-
Original price
$6,729.00
Original price
$6,729.00
$6,729.00
-
$6,729.00
Current price
$6,729.00
For in stock items, please refer to our shipping page for rates and transit times. If in a stocking warehouse, your order will arrive within the estimated delivery timeframe displayed above.
In the event of a delay, our customer service team will contact you with updated details and provide the option to cancel if the product cannot be delivered within the expected timeframe.
Cutting Diameter - in (DC): 12.402
Cutting Diameter - mm (DC): 315.0
Overall Length (OAL): 1.181
Tool Direction: Left
Shank: Shell mill DIN 8030 – disc mill
Cutter Design: S90CN(XN)
Cutting Edge Count: 20
EDP: 6760158
EAN: 3603602955043
MFG Part Number: 6760158
