DVPNR 2525 M 16
SKU DOR7028471
Primary Use:
Possible Use:
Double clamp turning tool for holding a 35° rhombus negative insert with an inscribed circle diameter of 9.525mm, 4.76mm thick (ISO designation VN.. 1604.. ), right hand 62.5°, left and right side cutting, 25mm tool height x 25mm width x 150mm long for chamfering, taper turning, single and multi-directional copy turning and longitudinal turning with and without shoulder
Inventory
Sold in packs of: 1
For more information about this product,
click here
Original price
$197.00
-
Original price
$197.00
Original price
$197.00
$197.00
-
$197.00
Current price
$197.00
For in stock items, please refer to our shipping page for rates and transit times. If in a stocking warehouse, your order will arrive within the estimated delivery timeframe displayed above.
In the event of a delay, our customer service team will contact you with updated details and provide the option to cancel if the product cannot be delivered within the expected timeframe.
Height: 0.984
Tool Direction: Right
Insert Designation: ["VN.. 1604.."]
Functional Length: 5.906
EDP: 7028471
EAN: 3603603105768
MFG Part Number: 7028471
