E770M12X1.25

E770M12X1.25

by Dormer Pramet
Primary Use: K - Cast Iron N - Non-Ferrous Metals

Straight flute tap White Shark with chamfer form C with a 2-3xP plug lead, for ISO-Metric Fine thread M12 with 1.25 mm pitch and D6 pitch diameter limits, dimensions according to DIN/ANSI standard with 0.3670" shank and 0.2730" square drive, powder metallurgical HSS-E with TiAlN-Top coating for 2xD through or blind hole threading in gray, malleable, ductile and compacted graphite cast-iron and polymers

Inventory
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)

Sold in packs of: 1

For more information about this product, click here
$32.02 - $32.02
$32.02 - $32.02
$32.02
$32.02 - $32.02
$32.02
Enjoy same-day shipping on orders placed before 2:30 PM MST. For in stock items, please refer to our shipping page for rates and transit times. If in a stocking warehouse, your order will arrive within the estimated delivery timeframe displayed above.

In the event of a delay, our customer service team will contact you with updated details and provide the option to cancel if the product cannot be delivered within the expected timeframe.

Material: HSS-E-PM

Lenxth x Diameter Ratio: 2

Overall Length (OAL): 3.937

Connetion Diameter: 0.367

Tool Direction: Right

Diameter Size: 12

Pitch - mm: 1.25

Pitch - in: 0.0492

Thread Form: MF - Metric fine

Shank: Cylindrical shank with Square

Grade: TiAlN/Top

EDP: 7350262

EAN: 7320760751060

MFG Part Number: 7350262
