RCMT 10T3MOSN-M:M8330
Single-sided milling insert RCMT 10T3 with chip-breakers, round for a maximum depth of cut of .1969", with " corner radius, an indexing accuracy according to ISO-tolerance class-M and M geometry with rounded cutting edges and facet, M8330 PVD coated fine grained WC-Co carbide within ISO-grade ranges P20-P40 and K20-K40 for machining of steel and cast-iron with copy face mills SRC10
Inventory
Sold in packs of: 10
In the event of a delay, our customer service team will contact you with updated details and provide the option to cancel if the product cannot be delivered within the expected timeframe.
Max. Depth of Cut: 0.197
Insert Design: RCMT
Insert Shape Code: R - round
Insert Thickness: 0.156
Steel and Cast Steel: Primary use
Stainless Steel: Possible use
Cast Iron: Primary use
High Temp Alloys: Possible use
Chip Breaker: M
Grade: M8330
EDP: 7445883
EAN: 3603603380073
MFG Part Number: 7445883
