CCMT 32.50.5-FM:T8430

CCMT 32.50.5-FM:T8430

SKU DOR7973813
by Dormer Pramet
Primary Use: P - Steel and Cast Steel M - Stainless Steel Possible Use: K - Cast Iron N - Non-Ferrous Metals

Single-sided positive turning insert, 80° rhomboid with 7° clearance, inscribed circle diameter of 9.525mm, 3.97mm thick, 0.2mm nose radius, indexing accuracy according to ISO-tolerance class-M, chip-breaker FM with rounded cutting edges, in grade T8430, a PVD coated fine grained WC-Co carbide within ISO ranges P20 -P40 and M20 -M35, for fine to medium machining of steels and stainless-steels

Inventory
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-7 Day Delivery)

Sold in packs of: 10

For more information about this product, click here
$0
$11.46 - $11.46
$11.46
$11.46 - $11.46
$11.46
Enjoy same-day shipping on orders placed before 2:30 PM MST. For in stock items, please refer to our shipping page for rates and transit times. If in a stocking warehouse, your order will arrive within the estimated delivery timeframe displayed above.

In the event of a delay, our customer service team will contact you with updated details and provide the option to cancel if the product cannot be delivered within the expected timeframe.

Insert Design: CCMT

Insert Shape Code: C - rhombic 80° included angle

Insert Shape Code: gid://shopify/Metaobject/130432860222

Insert Thickness: 0.156

Steel and Cast Steel: Primary use

Stainless Steel: Primary use

Cast Iron: Possible use

Non Ferrous: Possible use

Inscribed Circle Diameter: 0.375

Chip Breaker: FM

Grade: T8430

Corner Radius - in: 0.008

Corner Radius - mm: 0.2

EDP: 7973813

EAN: 3603603814134

MFG Part Number: 7973813
