RNMU 1004MOT-MM:M6030

RNMU 1004MOT-MM:M6030

SKU DOR8547774
by Dormer Pramet
Primary Use:

Double-sided milling insert RNMU 1004 with chip-breakers, round for a maximum depth of cut of 4.5mm, with an indexing accuracy according to ISO-tolerance class-M and MM geometry with rounded cutting edges and facet, M6030 PVD coated WC-Co carbide within ISO-grade ranges M15-M35 and S15-S25 for machining of stainless-steel and superalloy with copy face mills SRN10

Inventory
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)

Sold in packs of: 10

For more information about this product, click here
$18.09 - $18.09
$18.09
$18.09 - $18.09
$18.09
For in stock items, please refer to our shipping page for rates and transit times. If in a stocking warehouse, your order will arrive within the estimated delivery timeframe displayed above.

In the event of a delay, our customer service team will contact you with updated details and provide the option to cancel if the product cannot be delivered within the expected timeframe.

Connetion Diameter: 0.492

Insert Design: RNMU

Insert Shape Code: R - round

Insert Thickness: 0.1752

Cutter Design: SRN10

Stainless Steel: Primary use

High Temp Alloys: Primary use

Inscribed Circle Diameter: 0.3937

Chip Breaker: MM

Grade: M6030

EDP: 8547774

EAN: 3603604262101

MFG Part Number: 8547774
