RC3053/32

RC3053/32

SKU DOR8903918
by Dormer Pramet
Primary Use: Possible Use:

Cutting diameter 3/32 inches high-performance micro drill designed for precision applications, featuring a 140° point angle and capable of drilling up to 5xD with excellent surface quality. DCON MS 3 mm, LCF 20 mm and OAL 59 mm. Internal coolant enhances chip evacuation, while the advanced AlCrN coating provides outstanding wear resistance, thermal stability, and process reliability.

Inventory
🔗 Check Stock - ADC Warehouse (1-3 Day Delivery)
🔗 Check Stock - EDC Warehouse (4-10 Day Delivery)

Sold in packs of: 1

For more information about this product, click here
$187.00 - $187.00
$187.00
$187.00 - $187.00
$187.00
For in stock items, please refer to our shipping page for rates and transit times. If in a stocking warehouse, your order will arrive within the estimated delivery timeframe displayed above.

In the event of a delay, our customer service team will contact you with updated details and provide the option to cancel if the product cannot be delivered within the expected timeframe.

Material: HM

Coating: AlCrN

Cutting Diameter - in (DC): 0.094

Cutting Diameter - mm (DC): 2.381

Drill Point Angle - deg: 140

Flute Length: 0.787

Overall Length (OAL): 2.323

Connetion Diameter: 0.492

Shank: Cylindrical shank DIN 6535 HA

Functional Length: 0.63

Fractional: 3/32

Steel and Cast Steel: Primary use

Stainless Steel: Primary use

Cast Iron: Primary use

Non Ferrous: Primary use

High Temp Alloys: Possible use

EDP: 8903918

EAN: 3603607350683

MFG Part Number: 8903918
